Function name Signal type Signal name Description
AUTOREL Automatic release
MANREL Manual release
SLGAPC Analog inputs SWPOSN Switch position (integer)
Binary outputs CLOSE_CMD Close command parameter for DNP protocol
OPEN_CMD Open command parameter for DNP protocol
SMBI Binary inputs BI1 Binary input 1
BI2 Binary input 2
BI3 Binary input 3
BI4 Binary input 4
BI5 Binary input 5
BI6 Binary input 6
BI7 Binary input 7
BI8 Binary input 8
BI9 Binary input 9
BI10 Binary input 10
SMBO Binary inputs BO1 SMT Connect output
BO2 SMT Connect output
BO3 SMT Connect output
BO4 SMT Connect output
BO5 SMT Connect output
BO6 SMT Connect output
BO7 SMT Connect output
BO8 SMT Connect output
BO9 SMT Connect output
BO10 SMT Connect output
SMBRREC Binary inputs 1PT1 Single-phase reclosing is in progress, shot 1
2PT1 Two-phase reclosing is in progress, shot 1
3PT1 Three-phase reclosing in progress, shot 1
3PT2 Three-phase reclosing in progress, shot 2
3PT3 Three-phase reclosing in progress, shot 3
3PT4 Three-phase reclosing in progress, shot 4
3PT5 Three-phase reclosing in progress, shot 5
ACTIVE Reclosing sequence in progress
BLOCKED The AR is in blocked state
CLOSECMD Closing command for CB
READY Indicates that the AR function is ready for a new sequence
SETON The AR operation is switched on, operative
UNSUCCL Reclosing unsuccessful, signal resets after the reclaim time
Counters COUNT1P Counting the number of single-phase reclosing shots
COUNT2P Counting the number of two-phase reclosing shots
COUNT3P1 Counting the number of three-phase reclosing shot 1
COUNT3P2 Counting the number of three-phase reclosing shot 2
COUNT3P3 Counting the number of three-phase reclosing shot 3
COUNT3P4 Counting the number of three-phase reclosing shot 4
COUNT3P5 Counting the number of three-phase reclosing shot 5
Table continues on next page
Section 2 1MRK 511 419-UUS A
DNP3 data mappings
22 650 series 2.2 ANSI
Point list manual
