Function name Signal type Signal name Description
COUNTAR Counting total number of reclosing shots
SMPPTRC Binary inputs CLLKOUT Circuit breaker lockout output (set until reset)
TR1P Tripping single-pole
TR2P Tripping two-pole
TR3P Tripping three-pole
TRIP General trip output signal
TR_A Trip signal from phase A
TR_B Trip signal from phase B
TR_C Trip signal from phase C
SSCBR Binary inputs CBLIFEAL Remaining life of CB reduced to Life alarm level
GPRESALM Pressure below alarm level
GPRESLO Pressure below lockout level
SPCHALM Spring charging time has crossed the set value
Counter NOOPER Number of CB operation cycle
SSIMG Binary inputs PRES_ALM Pressure below alarm level
PRES_LO Pressure below lockout level
TEMP_ALM Temperature above alarm level
TEMP_LO Temperature above lockout level
SSIML Binary inputs LVL_ALM Level below alarm level
LVL_LO Level below lockout level
TEMP_ALM Temperature above alarm level
TEMP_LO Temperature above lockout level
SXCBR Analog inputs EEHEALTH External equipment health. 1=No warning or alarm, 2=Warning, 3=Alarm
Binary inputs CLOSEPOS Apparatus closed position
OPENPOS Apparatus open position
UPD_BLKD Update of position indication is blocked
Counters CNT_VAL Operation counter value
Double bit indications POSITION Apparatus position indication
TR_POS Truck position indication
SXSWI Analog inputs EEHEALTH External equipment health. 1=No warning or alarm, 2=Warning, 3=Alarm
Binary inputs CLOSEPOS Apparatus closed position
OPENPOS Apparatus open position
UPD_BLKD Update of position indication is blocked
Counters CNT_VAL Operation counter value
Double bit indications POSITION Apparatus position indication
T3WPDIF Binary inputs BLK2H Common second harmonic block signal from any phase
BLK5H Common fifth harmonic block signal from any phase
INTFAULT Indication that internal fault has been detected
OPENCTAL Open CT Alarm output signal. Issued after a delay ...
TRIP General, common trip signal
TRIPRES Trip signal from restrained differential protection
TRIPUNRE Trip signal from unrestrained differential protection
Table continues on next page
1MRK 511 419-UUS A Section 2
DNP3 data mappings
650 series 2.2 ANSI 23
Point list manual
