Function name Signal type Signal name Description
TRNSSENS Trip signal from sensitive negative sequence differential protection
TRNSUNR Trip signal from unrestrained negative sequence differential protection
TEIGAPC Binary inputs ALARM Indicator of the integrated time has reached the alarm limit
WARNING Indicator of the integrated time has reached the warning limit
TEILGAPC Binary inputs ALARM Indicator that accumulated time has reached alarm limit
Analog inputs ACC_DAY Accumulated time in days
ACC_HOUR Accumulated time in hours
Binary inputs OVERFLOW Indicator that accumulated time has reached overflow limit
WARNING Indicator that accumulated time has reached warning limit
TESTMODE Binary inputs BLOCK Active when LD0 is blocked or test blocked
IED_TEST IED test mode is active
TEST In test via IED TEST or via LD0 Mode
TMAGAPC Binary inputs OUTPUT1 OR function betweeen inputs 1 to 16
OUTPUT2 OR function between inputs 17 to 32
OUTPUT3 OR function between inputs 1 to 32
TRPTTR Binary inputs ALARM1 First level alarm signal
ALARM2 Second level alarm signal
LOCKOUT Lockout signal
TRIP Trip Signal
UV2PTUV Binary inputs TRST1 Common trip signal from step1
TRST1_A Trip signal from step1 phase A
TRST1_B Trip signal from step1 phase B
TRST1_C Trip signal from step1 phase C
TRST2 Common trip signal from step2
TRST2_A Trip signal from step2 phase A
TRST2_B Trip signal from step2 phase B
TRST2_C Trip signal from step2 phase C
TRIP Trip
VMMXU Analog inputs VAB VAB Reported magnitude value
VAB_ANGL VAB Angle, magnitude of reported value
VBC VBC Reported magnitude value
VBC_ANGL VBC Angle, magnitude of reported value
VCA VCA Reported magnitude value
VCA_ANGL VCA Angle, magnitude of reported value
VMSQI Analog inputs 3V0 3V0 Reported magnitude value
3V0ANGL 3V0 Magnitude angle
V1 V1 Reported magnitude value
V1ANGL V1 Magnitude angle
V2 V2 Reported magnitude value
V2ANGL V2 Magnitude angle
Table continues on next page
Section 2 1MRK 511 419-UUS A
DNP3 data mappings
24 650 series 2.2 ANSI
Point list manual
