Function name Signal type Signal name Description
VNMMXU Analog inputs VA VA Amplitude, magnitude of reported value
VA_ANGL VA Angle, magnitude of reported value
VB VB Amplitude, magnitude of reported value
VB_ANGL VB Angle, magnitude of reported value
VC VC Amplitude, magnitude of reported value
VC_ANGL V_C Angle, magnitude of reported value
VSGAPC Binary inputs POS1 Position 1 indication, logical signal
POS2 Position 2 indication, logical signal
Double bit indications POSITION Position indication, integer
Binary outputs CLOSE_CMD Close command parameter for DNP protocol
OPEN_CMD Open command parameter for DNP protocol
ZCLCPSCH Binary inputs TRLL Trip by loss of load
TRZE Trip by zone extension
ZCPSCH Binary inputs CS Pilot channel start signal
LCG Loss of channel guard signal output from communication scheme logic
PRORX Teleprotection permissive signal received from remote end
TRIP Trip by pilot communication scheme logic
ZCRWPSCH Binary inputs ECHO A signal that indicates channel start (CS) by WEI logic
TRWEI Trip signal from weak end infeed logic
TRWEI_A Trip signal from weak end infeed logic in phase A
TRWEI_B Trip signal from weak end infeed logic in phase B
TRWEI_C Trip signal from weak end infeed logic in phase C
ZCVPSOF Binary inputs TRIP Trip by pilot communication scheme logic
ZMFPDIS Binary inputs TRIP Trip in any phase or phases from any zone or zones
TRZ1 Trip in any phase or phases from zone 2 - forward direction
TRZ2 Trip in any phase or phases from zone 2 - forward direction
TRZ3 Trip in any phase or phases from zone 3 - zone direction
TRZ4 Trip in any phase or phases from zone 4 - zone direction
TRZ5 Trip in any phase or phases from zone 5 - zone direction
TRZRV Trip in any phase or phases from zone RV - reverse dir.
1MRK 511 419-UUS A Section 2
DNP3 data mappings
650 series 2.2 ANSI 25
Point list manual
