3.9 ANALOG INPUTS
Static (Steady-State)
Group Number: 30
Static Frozen Group
Number: 31
Event Group Number: 32
Frozen Analog Input
Event Group Number: 33
Deadband Group
Number: 34
Capabilities
(leave tick-boxes blank if
this data type is not
supported)
Current Value
If configurable, list
methods
● Variation 1 – 32-bit
without time
One PST or LHMI
(Obj32DefVar)
● Variation 2 – 16-bit
without time
● Variation 3 – 32-bit
with time
● Variation 4 – 16-bit
with time
● Variation 5 – single-
precision floating point
w/o time
● Variation 6 – double-
precision floating point
w/o time
● Variation 7 – single-
precision floating point
with time
● Variation 8 – double-
precision floating point
with time
○ Based on point Index
(add column to table in
part 5)
3.9.3 Event reporting mode: When responding with event data and more than one event has occurred for
a data point, an Outstation may include all events or only the most recent event. Only the most recent
event is typically reported for Analog Inputs. When reporting “only most recent”, the analog value reported
in the response may be the value at the time of the original event or it may be the value at the time of the
response.
● A: Only most recent
(value at time of event)
Most Recent – Event
Time
● B: Only most recent
(value at time of
response)
● C: All events
○ Based on point Index
(add column to table in
part 5)
3.9.4 Analog Inputs Included in Class 0 response:
Table continues on next page
