ABB REF601 Product Guide

ABB 11
1MDB07207-YN
Feeder Protection
REF601
Product version: 2.0
Description
Type test value Reference
Emission tests:
IEC 60255-25
EN 55011-CISPR II
• Conducted
150 kHz-0.5 MHz
Table 13. Electromagnetic compatibility tests, continued
• Radiated
Table 14. Insulation tests
Description
Type test value Reference
Dielectric test
IEC 60255-5
IEC 60255-27
IEC 60255-27
Insulation resistance test
IEC 60255-5
IEC 60255-27
> 100 M Ω at 500 V DC
• Isolation resistance
Table 15. Mechanical tests
Description
Type test value Reference
Vibration tests
IEC 60255-21-1, class II
10...150 Hz, 0.035 mm / 1.0 g,
• Response
1 sweep / axis
• Endurance / Withstand
10...150 Hz, 2.0 g,
20 sweeps / axis
Shock tests
IEC 60255-21-2, class II
10 g, 3 pulses in each direction
• Response
• Endurance / Withstand
30 g, 3 pulses in each direction
Bump tests
IEC 60255-21-2, class II
20 g, 1000 bumps in each direction
2 kV, 50 Hz, 1 min
• Test voltage
Impulse voltage test
IEC 60255-5
5 kV, 1.2/50 μs, 0.5 J
• Test voltage
0.5 MHz-30 MHz
30-230 MHz
230-1000 MHz
< 40 dB ( μV/m)
< 47 dB ( μV/m)
< 66 dB ( μV/m)
< 60 dB ( μV/m)

ABB REF601 Specifications

General

Brand	ABB
Model	REF601
Category	Protection Device
Language	English
