Feeder Protection
REF601
Product version: 2.0
20. Accessories and ordering data
Table 26. Compatible sensors
Item
Order number
KEVCR for integrated circuit-breakers type VD4/HD4
KEVCR24OC2R0101, 630A
KEVCR24AC2R0102, 1250A
KECA for other applications where relay is panel mounted
KECA 250 B1 :
1VL5400052V0101
For more information please refer to the catalogue reference
- no. 1VLC000584.
Figure 5. Outline view of KEVCR sensor
Figure 6. Outline view of KECA sensor
