Feeder Protection and Control
REF615
Product version: 2.0
1MRS756379 D
Table 18. Insulation tests
Description Value
Dielectric tests: According to IEC 60255-5
• Test voltage 2 kV, 50 Hz, 1 min
500 V, 50 Hz, 1min,
communication
Impulse voltage test: According to IEC 60255-5
• Test voltage 5 kV, unipolar impulses,
waveform 1.2/50 μs, source
energy 0.5 J
1 kV, unipolar impulses,
waveform 1.2/50 μs, source
energy 0.5 J, communication
Insulation resistance measurements According to IEC 60255-5
• Isolation resistance >100 MΩ, 500 V DC
Protective bonding resistance
• Resistance
According to IEC 60255-27
<0.1 Ω (60 s)
Table 20. EMC compliance
Complies with the EMC directive 2004/108/EC
Standards EN 50263 (2000),
EN 60255-26 (2007)
Table 21. Product safety
Complies with the LV directive 2006/95/EC
Standards EN 60255-27 (2005),
EN 60255-6 (1994)
Data communication interfaces
Table 23. Ethernet interfaces
Ethernet interface Protocol Cable Data transfer rate
Front TCP/IP
protocol
Standard Ethernet CAT5 crossover
cable with RJ-45 connector
10 MBits/s
Rear TCP/IP
protocol
Shielded twisted pair CAT 5e cable
with RJ-45 connector or fibre-optic
cable with LC connector
100 MBits/s
Table 22. RoHS compliance
Complies with the RoHS directive 2002/95/EC
Table 19. Mechanical tests
Description Value
Vibration tests (sinusoidal) According to IEC 60255-21-1,
class 2
Shock and bump test According to IEC 60255-21-2,
class 2
