ABB 43
Feeder Protection and Control
REF615
Product version: 2.0
1MRS756379 D
H B F C A C A B N B B 1 A C N 1 X C
# DESCRIPTION
12 Language
English 1
English and German 3
13 Front panel
Small LCD A
Large LCD B
14 Option 1
Auto-reclosing A
Arc protection
1)
B
Arc protection and auto-reclosing
1)
C
None N
15 Option 2
None N
16 Power supply
48...250 V DC, 100...240 V AC 1
24...60 V DC 2
17 Vacant digit
Vacant X
18 Version
Version 2.0 C
1)
The arc protection hardware is located on the
communication module (digit 9-10). Thus a communication
module is always required to enable arc protection. Note
that arc protection or arc protection and reclosing cannot
be combined with serial communication using glass fi bre (ST).
Fig. 13 Ordering key for complete IEDs
Example code: H B F C A C A B N B B 1 A C N 1 X C
Your ordering code:
Digit (#) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
Code
                 
