ABB 52
Feeder Protection and Control
REF615
Product version: 2.0
1MRS756379 D
Functions IEC 61850 IEC
60617
ANSI
Trip circuit supervision TCSSCBR TCS TCM
Circuit-breaker condition monitoring SSCBR CBCM CBCM
Disconnector position indication DCSXSWI I <-> O DC I <-> O DC
Earthing switch indication ESSXSWI I <-> O ES I <-> O ES
Measurement functions
Three-phase current CMMXU 3I 3I
Current sequence components CSMSQI I
1
,
I
2
,
I
0
I
1
,I
2
,I
0
Three-phase voltage measurement VMMXU1 3U 3U
Voltage sequence components VSMSQI1 U
1
, U
2
, U
0
U
1
, U
2
, U
0
Residual current RESCMMXU I
0
I
N
Residual voltage RESVMMXU U
0
V
N
Power and energy PEMMXU1 P, E P, E
Disturbance recorder function
Transient disturbance recorder RDRE DREC DREC
