1MDU07212-YN Rev. C Section 6
Installation
REF601 / REJ601 67
Application Manual
Table 30: Configuration
Configuration
Parameter
Actual
value
Default
value
Unit
Range
Resolution
Blocking: I> / 51 NO - NO; YES -
Blocking: I>> / 50-1 NO - NO; YES -
Blocking: I>>> / 50-2 NO - NO; YES -
Blocking: Io> / 51N NO - NO; YES -
Blocking: Io>> / 50N NO - NO; YES -
Blocking: 3Ith> / 49 NO - NO; YES -
Blocking: I2> / 46 NO - NO; YES -
Blocking: I2/I1> / 46PD NO - NO; YES -
Blocking: BF NO - NO; YES -
Blocking: O -> I / 79 NO - NO; YES -
Blocking Remote Ctrl NO - NO; YES -
Block TCS NO - NO; YES -
TCS Operate Time 5 sec 1 … 300 1
Earth type / I0 meas. External Internal; External -
CT Ipn 1000 A 20 … 9999 1
CT Isn 1 A 1; 5 -
Frequency 50 Hz 50; 60 -
COM Parameters
Protocol
MODBUS RTU
IEC 60870
-
5
-
103
Comm. Baud Rate 19200 -
MODBUS:
2400; 4800; 9600;
19200; 38400
IEC_103:
9600; 19200
-
Relay Addr 001 -
MODBUS:
001 … 247
IEC_103:
001…254
-
Comm. Parity Even -
MODBUS:
None; Odd; Even
IEC_103: None; Even
-
Class2 Intv (IEC_103) 10 sec 0…60 sec
Class2 SF 2.4 1.2; 2.4
Comm Admin Level Yes - NO; YES -
