Section 6 1MDU07212-YN Rev. C
Installation
68 REF601 / REJ601
Application Manual
Table 31: Binary Input configuration
Binary input
Connected
to signal
BI1 BI2 BI3 BI4
Input behavior: inversion (-) (-) (-) (-)
Block : I> / 51
Block : I>> / 50-1
Block : I>>> / 50-2
Block : Io> / 51N
Block : Io>> / 50N
Blocking: 3Ith> / 49
Blocking: I2> / 46
Blocking: I2/I1> / 46PD
Blocking: BF
Blocking: BF ProtExt
Blocking: BF RecTrip
CB Ready
Blocking: O -> I / 79
Block : CB Control
Reset (x)
CB Close Position
CB Open Position
CB Maintenance (Test)
TCS (x)
TCS Block
External Trip (x)
External Close
Power off
Signal 1
Signal 2
Signal 3
SG Select
Input behavior: “-“ = Non inverted, “I” = Inverted
Remark: “(..)” = Default setting
Table 32: Binary Output configuration
Binary output
Signal to
activate output
BO1 BO2 BO3 BO4 BO5 BO6
Output behavior: inversion (-) (-) (-) (-) (-) (-)
Output behavior: duration (P) (P) (P) (S) (P) (P)
Start : I> / 51
Start : I>> / 50-1
Start : I>>> / 50-2
Start : Io> / 50N-1
Start : Io>> / 50N-2
