ABB REL 356

Quick Start Guide For The DNP Orion To ABB REL 356 Relays Using Modbus AN-55A-00
3
PWR FUSE
SCADA
DIAG
PC
IED
POS NEG GND
MODEL # _____
SERIAL # _____
TEST DATE ___
SCADA HOST
Illustration 1
ABB Orion Rack Mount Connectivity Diagram
Illustration 5
3
55 56 57 58 59 60 61 -----
RS 485 AUX COM
Isolated Port
Shield Bare Wire
Illustration 6
DEBUG
Computer
Illustration 7
MODEL # _____
SERIAL # _____
TEST DATE
A B Shld
IED
55 56 57 58 59 60 61 -----
RS 485 AUX COM
Isolated Port
Shield Bare Wire
Relay Pin 55 to Orion Terminal B ( TX/RX +)
Relay Pin 56 to Orion Terminal A ( TX/RX -)
Relay Pin 57 to Orion Terminal Shld ( Ground)
Illustation 2
Figure 2 – Orion Cable Connection Diagram
SCADA HOST
A B Shld
RS 485 PONI -M
Modbus Port
Shield Bare Wire
Illustration 6
DEBUG
Computer
Illustration 5
Illustration 7
PWR
POS NEG GND
SCADA
MODEM/
DIAGNOSTIC
IED
55-150 VAC
20 -150 VDC
Illustration 1
Illustration
7
TABLE TOP
CABLE LOCATION
Figure 2A – Orion Table Top Cable Connection Diagram
