Quick Start Guide For The DNP Orion To ABB REL 356 Relays Using Modbus AN-55A-00
9
+--------------¦ NovaTech Conitel-Modbus Configuration Program ¦---------------+
¦ PRINTER: READY FILE NAME: TEST.CTL ¦
¦ File Setup Memory Map Transfer About 10:37:10 ¦
¦¦¦¦¦¦¦¦¦+------------------------+¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ PC-P+-------¦ Modbus Communication Setup ¦--------+¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ Prot¦ ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ Prot¦ Baud Rate Parity Data Bits Stop Bits ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦+------¦ ( )300 ( )NONE ( )6 (¦
)1 ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦ ( )600 ( )ODD ( )7 ( )2 ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦+--------------¦ ( )1200 (¦)EVEN (¦)8 ¦---------------+¦
¦¦Current Video ¦ ( )2400 ¦ ¦¦
¦¦ ¦ ( )4800 WarmUp Time [ms]: 10 ¦ ¦¦
¦¦ ¦ (¦)9600 WarmDown Time [ms]: 10 ¦ ¦¦
¦¦ ¦ ( )19200 Response Timeout [ms]: 1000 ¦ ¦¦
¦¦ ¦ Intercommand Delay [ms]: 100 ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ +---------------------------------------------+ ¦¦
¦¦ ¦¦
¦¦ ¦¦
¦¦ ¦¦
¦+-----------------------------¦ Message Window ¦-----------------------------+¦
+------------------------------------------------------------------------------+
<Tab>: Next Field <Esc>: Abort <Ctrl>+<Enter>: Accept
Figure 9 - Orion MODBUS IED Port Configuration Screen.
12. With the “SETUP” parameter highlighted, select the PROTCONV CONITEL Setup submenu
selection, until the following screen is displayed. The parameters listed in Figure 6 match those in the
CONITEL Host. After selection of all parameters, simultaneously depress the “CONTROL and
ENTER” key on the configuration terminal’s keyboard.
+--------------¦ NovaTech Conitel-Modbus Configuration Program ¦---------------+
¦ PRINTER: READY FILE NAME: TEST.CTL ¦
¦ File Setup Memory Map Transfer About 10:37:15 ¦
¦¦¦¦¦¦¦¦¦+------------------------+¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ PC-+¦ Edit Conitel Comm Parameters ¦----------------+¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ Pro¦ ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦ Pro¦ Station Address: 1 ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦+-----¦ Baud Rate: 1200 ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦ Warmup Time [ms]: 40 ¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦¦
¦+-------------¦ Warmdown Time [ms]: 0 ¦-------------+¦
¦¦Current Video¦ Timeout [ms]: 800 ¦ ¦¦
¦¦ ¦ PLC with Reset Coil: 1 ¦ ¦¦
¦¦ ¦ Reset Coil: 9999 ¦ ¦¦
¦¦ ¦ Check Back Before Operate Time [ms]: 1000 ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ ¦ ¦ ¦¦
¦¦ +------------------------------------------------+ ¦¦
¦¦ ¦¦
¦¦ ¦¦
¦¦ ¦¦
¦¦ ¦¦
¦+-----------------------------¦ Message Window ¦-----------------------------+¦
+------------------------------------------------------------------------------+
<Esc>: Abort <Ctrl>+<Enter>: Accept New Parameters
Figure 10 – CONITEL Configuration Screen For The Orion SCADA Port
