ABB Relion 605 Series User Manual

1MDU07212-YN Rev. D Section 5
Use of LHMI
REF601 / REJ601 / REM601 51
Application Manual
5.2.6 Menu – Setting
Submenu Settings and respective submenus shows and allows depending on the
user right to change all protection parameters and communication parameters.
Remark:
 To modify settings needs user rights of Setting or Admin user.
 To modify selected setting start with key
 To save changed setting with key .
 To discard and exit a modified setting with key /
 View of time parameters of I> and I0> (k / t> respective k/t0>) are depending
on the selection of the curve selection of its function.
If COM Admin Level is YES, then IED configuration parameter
is allowed to change through MODBUS
Following menu structure is used to navigate to the respective settings:

ABB Relion 605 Series Specifications

General

Series	Relion 605
Manufacturer	ABB
Input Voltage	24-250 V DC, 100-240 V AC
Display	LCD
Communication Protocols	IEC 61850, DNP3, Modbus
Mounting Type	Rack
Operating Temperature	-40 to +70 °C
Protection Functions	Overcurrent, earth fault, thermal overload, frequency protection
Dimensions	Varies by model
Weight	Varies by model
