8 REM615 ANSI 5.0 FP1 MOTOR PROTECTION AND CONTROL
—

Description Std. conf.
Basic motor protection (RTD option) A
Motor protection with voltage & frequency based protection and measurements (RTD option), remanent voltage B
Motor protection with voltage & frequency based protection and measurements (Sensor inputs), remanent voltage D
Differential (core balance and true), overcurrent, load loss, phase and neutral voltage, frequency and RTD protection, power protection and
power system metering for medium to large motors E
—

Function  ANSI A B D E
Protection
Three-phase non-directional overcurrent protection, low stage PHLPTOC     
Three-phase non-directional overcurrent protection, high stage PHHPTOC  






Three-phase non-directional overcurrent protection,
instantaneous stage
PHIPTOC     
Non-directional earth-fault protection, low stage EFLPTOC  



Non-directional earth-fault protection, high stage EFHPTOC  







Directional earth-fault protection, low stage DEFLPDEF  




Residual overvoltage protection ROVPTOV  

Three-phase undervoltage protection PHPTUV    
Three-phase overvoltage protection PHPTOV  
Positive-sequence undervoltage protection PSPTUV    
Negative-sequence overvoltage protection NSPTOV    
Three-phase remnant undervoltage protection MSVPR    
Frequency protection FRPFRQ    
Overexcitation protection OEPVPH  
Negative-sequence overcurrent protection for machines MNSPTOC     
Loss of load supervision LOFLPTUC     
Motor load jam protection JAMPTOC     
Motor start-up supervision STTPMSU     
Phase reversal protection PREVPTOC     
Thermal overload protection for motors MPTTR     
Motor differential protection MPDIF 
High-impedance differential protection for phase A   
IA, (BS)
High-impedance differential protection for phase B HIBPDIF  
IB, (BS)
High-impedance differential protection for phase C HICPDIF  
IC, (BS)
Circuit breaker failure protection CCBRBRF     
Master trip TRPPTRC  























Arc protection ARCSARC AFD    
  MAP 









Underpower protection DUPPDPR  
 DOPPDPR  
Control
Circuit breaker control CBXCBR     
Disconnector control DCXSWI     
Earthing switch control ESXSWI     
Disconnector position indication DCSXSWI  








ABB REM615 ANSI 5.0 FP1 Specifications

General

Standard	ANSI
Version	5.0 FP1
Rated Frequency	50/60 Hz
Housing	Plastic
Type	Feeder protection relay
Communication Protocols	Modbus, IEC 61850, DNP3
Mounting	Flush mounting
Operating Temperature Range	-40 to +70 °C
Protection Functions	Overcurrent, Earth fault, Thermal overload
Protection Degree	IP54
Input Voltage	24-250 V DC / 48-265 V AC
