ABB REQ650 - Page 15

IEC 61850/Function
block name
ANSI Function description Breaker
REQ650
REQ650 (A01)
3Ph/1CB/1BB
REQ650 (A11)
1Ph/1CB/1BB
REQ650 (B11)
1Ph/1CB/2BB
RS485103 IEC60870-5-103 serial
communication for RS485
1 1 1 1
GOOSEINTLKRCV Horizontal communication via
GOOSE for interlocking
59 59 59 59
GOOSEBINRCV GOOSE binary receive 4 4 4 4
ETHFRNT
ETHLAN1
GATEWAY
Ethernet configuration of front
port, LAN1 port and gateway
1 1 1 1
GOOSEDPRCV GOOSE function block to
receive a double point value
32 32 32 32
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand value
16 16 16 16
GOOSESPRCV GOOSE function block to
receive a single point value
64 64 64 64
Breaker protection REQ650 1MRK 505 283-BEN -
Product version: 1.2
ABB 15
