20. Ordering for Configured IED
Guidelines
Carefully read and follow the set of rules to ensure problem-free order management.
Please refer to the available functions table for included application functions.
To obtain the complete ordering code, please combine code from the tables, as given in the example below.
Exemple code: REQ650*1.2-A01X00-X00-B1A5-B-A-SA-AB1-RA3-AXXX-E. Using the code of each position #1-11
specified as REQ650*1-2 2-3-4 4-5-6-7 7-8 8-9 9-10 10 10 10-11
# 1 - 2 - 3 - 4 - 5 6 - 7 - 8 - 9 - 10 - 11
REQ650* - - - - - - - - -
Position
SOFTWARE #1 Notes and Rules
Version number
Version no
1.2
Selection for position #1. 1.2
Configuration alternatives #2 Notes and Rules
Single breaker, 3-phase, 1 busbar A01
Single breaker, single phase, 1 busbar A11
Single breaker, single phase, 2 busbars B11
ACT configuration
ABB standard configuration X00
Selection for position #2. X00
Software options #3 Notes and Rules
No option X00
Selection for postition #3 X00
First HMI language #4 Notes and Rules
English IEC B1
Selection for position #4.
Additional HMI language #4
No second HMI language
X0
Selection for position #4.
B1
X0
Casing #5 Notes and Rules
Rack casing, 3U 1/1 x 19" D
Selection for position #5. D
Breaker protection REQ650 1MRK 505 283-BEN -
Product version: 1.2
ABB 89
To Next Page
