Mounting details with IP40 of protection from the front #6 Notes and Rules
No mounting kit included X
Rack mounting kit for 3U 1/1 x 19" H
Selection for position #6.
Connection type for Power supply, Input/output and
Communication modules
#7 Notes and Rules
Compression terminals S
Ringlug terminals R
Power supply
Slot position:
pPSM
100-240V AC, 110-250V DC, 9BO A
48-125V DC, 9BO B
Selection for position #7.
Human machine interface #8 Notes and Rules
Local human machine interface, OL8000, IEC
3U 1/1 x 19", Basic
E
Detached LHMI
No detached mounting of LHMI X0
Selection for position #8. E X0
Connection type for Analog modules #9 Notes and Rules
Compression terminals S
Ringlug terminals R
Analog system
Slot position:
p2
Transformer module, 4I, 1/5A+1I, 0.1/0.5A+5U,
100/220V
A3
Selection for position #9. A3
Binary input/output module #10 Notes and Rules
Slot position (rear view)
p3
p4
p5
p6
Available slots in 1/1 case
No board in slot X X X
Binary input/output module 9 BI, 3 NO
Trip, 5 NO Signal, 1 CO Signal
A A A A p4, p5, p6 optional for A01
p4=A, p5, p6 optional for A11/B11
Selection for position #10. A
Breaker protection REQ650 1MRK 505 283-BEN -
Product version: 1.2
90 ABB
