Section 7 1MAC303209-MB C
Technical data
34 620 series
Installation Manual
Table 4: Dimensions
7.2.1 Enclosure class
Table 5: Degree of protection of flush-mounted IED
Description Value
Width frame 10.32 inches (262.2 mm)
case 9.69 inches (246 mm)
Height frame 6.97 inches (177 mm), 4U
case 6.30 inches (160 mm)
Depth 7.91 inches (201 mm)
Weight Complete IED 10.5 lbs (4.8 kg)
Plug-in unit only 6.0 lbs (2.8 kg)
Description Value
Front side IP 54
