1.4. Calibration scales and correct axis position
3HAC 16578-1 Revision: E22
© Copyright 2003-2007 ABB. All rights reserved.
&DOLEUDWLRQVFDOHV,5%
The illustration below shows the positions of the calibration marks on all axes of the robot.
xx0600003096
A Calibration scale, axis 1
B Calibration scale, axis 2
C Calibration scale, axis 3
D Calibration scale, axis 4
E Calibration scale, axis 5
F Calibration scale, axis 6
