1.4. Calibration scales and correct axis position
233HAC 16578-1 Revision: E
© Copyright 2003-2007 ABB. All rights reserved.
&DOLEUDWLRQVFDOHVPDUNV,5%
The figure below shows the positions of the calibration marks on the robot.
xx0700000148
A Calibration plate, axis 1
B Calibration tab on robot
C Calibration mark, axis 2
D Calibration mark, axis 3
E Calibration mark, axis 4
F Calibration mark, axis 5
G Calibration mark, axis 6
