2.4. Checking of sensors

353HAC 16578-1 Revision: E

4. Remove the sensor, turn it 180° and refit it

in the corresponding hole pattern. wait a

couple of seconds until the sensor has

been stabilized.

1RWH'RQRWFKDQJHWKHSRVLWLRQRIWKH

FDOLEUDWLRQSODWH

xx0300000261

5. Read the values for “A” and “B” shown by

the instrument. The difference between the

two readings should be less than 0.002°

and have opposite directions (+/-). If the

difference is greater, the sensor must be

recalibrated.

Detailed in step 1-15 in &DOLEUDWLRQRI

VHQVRUVRQSDJH.

$FWLRQ 1RWH,OOXVWUDWLRQ

&RQWLQXHG
