Mounting Equipment Section 2 Product Description
100 3BSE015969-600 A
There are 9 different configuration alternatives for mounting of MTUs, see
Figure 47.
Prefabricated Aluminium Profile
Prefabricated aluminium profile for mounting of S800 I/O modules in cabinets or
other types of installations. The profile supports good mechanical stability and
chassis ground connection.
There are aluminium profiles for horizontal 465 mm (19”), 592 mm (24”) or
719 mm (28.31”) mounting, see Figure 48.
Figure 47. Configurations for mounting of MTUs on the Mounting Kit
TU840/TU848 TU841/TU849TB845 TB805 TB845TU846 TB805TU847
TB846 TU846 TB845 TB806 TU847 TB805 TU807 TB805
TB806 CI801 TB805 CI801 TB805
