Figure 48. MTU mounted on aluminium profile
Screws for fastening in
environments with
high vibrations
Groove for
fastening screws
Section 2 Product Description Mounting Equipment
3BSE015969-600 A 101
The profile has grooves for self-tapping screws (ST 4.8×9.5) that can be used for
fastening the modules in an environment with high vibrations.
The aluminum profiles have one DIN-rail and one cable duct and are available in
different sizes.
