XT2 - XT4 F
XT2 - XT4 F
SACE Tmax XT | ABB
PIN SIGNAL
1 VCOM
2 Ne+
3 Szc
4 Ne-
5 Szi
6 Gzo
7 Gzi
8 Szo
9 K1
10 K2
11 W3
12 W4
11 12
1 2
VCOM
Ne+
Szc
Szi
Gzi
K1
W3
Ne-
Gzo
Szo
K2
W4
1
2
B C
