Item No. 421, Order No. : GPDT 06 0004 R56
Connecting set, (motor-operated) mechanism, earthing switch
(mounting, operating mechanism and operating linkage
Items No. Description Size Qty. Standard
421-303 Hexagon screw M16x60 2 DIN 933 8.8-tzn
421-306 Hexagon screw M16x30 2 DIN 933 8.8-tzn
421-323 Hexagon nut BM16 2 DIN 439 A2-70
421-325 Lock nut VM16 2 DIN 980 A2-70
421-340 Washer A17 6 DIN 125 A2-70
Item No. 422, Order No. : GPDT 06 0004 R51
Connecting set, pivot bearing, disconnecetor
(Separate mounting of motor-operated or manual operating mechanism)
(mounting, pivot bearing and operating linkage)
Items No. Description Size Qty. Standard
422-303 Hexagon screw M16x60 1 DIN 933 8.8-tnz
422-307 Hexagon screw M16x40 2 DIN 933 8.8-tnz
422-309 Hexagon screw M16x80 1 DIN 933 8.8-tnz
422-320 Hexagon nut M16 4 DIN 934 8-tnz
422-323 Hexagon nut BM16 1 DIN 439 A2-70
422-325 Lock nut VM16 2 DIN 980 A2-70
422-340 Washer A17 6 DIN 125 A2-70
Item No. 423, Order No. : GPDT 06 0004 R57
Connecting set, pivot bearing, earthing switch
(separate mounting of motor-operated or manual operating mechanism)
(Mounting, pivot bearing and operating linkage)
Item No. Description Size Qty. Standard
423-303 Hexagon screw M16x60 2 DIN 933 8.8-tzn
423-307 Hexagon screw M16x40 2 DIN 933 8.8-tzn
423-320 Hexagon nut M16 2 DIN 934 8-tnz
423-323 Hexagon nut BM16 2 DIN 439 A2-70
423-325 Lock nut VM16 2 DIN 980 A2-70
423-340 Washer A17 6 DIN 125 A2-70
Item No. 430, Order No. GPDT 06 4000 R60
Connecting set, mounting, earthing switch
(flexible connections and tubular contact arm, 1 x per pole)
Item No. Description Size Qty. Standard
430-305 Hexagon screw M12x45 3 DIN 933 8.8-tnz
430-308 Hexagon screw M12x20 2 DIN 933 A2-70
430-324 Hexagon nut M12 3 DIN 934 A2-70
430-341 Washer A13 6 DIN 125 A2-70
430-350 Clamp sleeve 12x30 1 DIN 1481 nrFdSt
430-353 Clamp sleeve 16x22 3 DIN 7346
96/113
1HDB 050016-YN-A
