10 Spare Parts
It is recommeded to keep the following parts in stock so that, in case of disturbances, prolonged
periods of interruption are avoided by rapidly replacing the individual parts. When ordering spare
parts, indicate the following details :
a) Type and serial number according to the rating plate of the specific unit.
b) Designation of spare part, item no. and order no. in accordance with these instructions.
c) Motor, control, heating and blocking magnet voltage.
Designation Identification
letter
Fig.Item
Sr. No.
Order No.Quantity
per
operating
mechanism
Motor (with pinion) for MT 50/MT 100 M 1 1 1
operating voltage 110...125 V DC 1HYN050001R601
220...250 V DC 1HYN050001R602
Cabon brush for motor - - - 2 1HYN350028P98
Rectifier 15 A G1 37 1 1 1HYN450040P1
Peak block voltage 500 V AC
Control contactor K1E, K2A 6 1 2
operating voltage 220 V AC, 50 Hz 1HYN450102P1
110 V DC 1HYN450102P2
125 V DC 1HYN450102P3
220 V DC 1HYN450102P4
Additional : auxiliary contact 1 NC + 1 NO 1HYN450102P5
1 NC + 3 NO 1HYN450102P23
Miniature Circuit Breaker 6 A AC 108 1HYN450102P6
for Motor and Control circuit 6 A AC 1HYN450102P8
for Heating and Lighting circuit 3 A AC 90 1HYN450102P20
Auxiliary switch elements with roller As per specific 1HYN450103R2
BLUE scheme and
BLACK order
Auxiliary switch elements without roller
(required for double decker
arrangement)
BLUE 1HYN450103R3
BLACK
Limit switch S1E, S2A 17 1 2 1HYN450013P1
Safety contact S3 14 1 1 1HYN450017P1
Blocking magnet Y1 19 1 1
110 V DC 1HYN350027P15
125 V DC 1HYN350027P13
220 V DC 1HYN350027P11
Inter-locking switch
(at blocking magnet) Y1-S3V 51 1 1HYN450039R1
Anticondensation heater
operating voltage 220...250 V AC R1 11 1 1 MT430162P20
Thermostat 23T 11 1 1 1HYN450182P1
Door sealing gasket - 21 1 1 piece 1HYN450193P1
approx. 2 m
Sealing ring - 2 1HYN450038P1
Molycote longterm 2 plus - 1 can 250 gm GON598000P521
Dowty seal - 2 1HYN450042P111
Retaining ring - 2 1HYN450107P1
Cylindrical pin f12 - 1 1HYN450095P1
Roll pin 3.5x16 - 1 MT430189P262
Split pin 3.5x22 - 1 MT430405P2312
