Figure 32 : Mounting of coupling of disconnectors : Mounting of operating rod (37) if operating mechanism for
disconnector at opposite opening side
Item numbers 420-... : Direct mounting
Item numbers 422-... : Separate mounting
39/113
1HDB 050016-YN-A
