ABB Smile 41 AS-i Series

2TLC172255M0201, rev. D
13
www.abb.com/jokabsafety
For the North American market (UL)
Enclosure
Type 1
Cable assemblies
Must comply with CYJV/7. Cord provided shall be 24 AWG (0.2mm
2
) minimum
Power source
The Limited voltage source must comply with:
a) The maximum open circuit voltage potential available to the circuit shall not be
more than 42.4 V peak;
b) All external circuit interconnecting cable cables shall be protected against
burnout and damage to the insulation resulting from any overload or short
circuit condition per the following table, based on the cable conductor size.
Conductor size
Maximum ampere ratings of the overcurrent protection.
AWG (mm) Ampere.
22 (0.32) 3
20 (0.52) 5
18 (0.82) 7
16 (1.3) 10
14 (2.1) 20
12 (3.3) 50
Safety / Harmonized Standards
Conformity
European Machinery Directive 2006/42/EC
EMC 2014/30/EU
RoHS 2011/65/EU
EN ISO 12100:2010, EN ISO 13849-1:2015, EN 62061:2005/A2:2015,
EN 60204-1:2006+A1:2009, IEC 60664-1:2007, EN 61000-6-2:2005,
EN 61000-6-4:2011, EN ISO 13850:2015,
EN 60947-5-5:2005, EN 61508:2010
IEC/EN 61508-1…7
SIL3, PFD
avg
: 2.95*10
-6
, PFH
D
: 6.95*10
-9
EN 62061
SIL3
EN ISO 13849-1
Performance level: PL e, category 4
MTTF
D
: High
EN 60947-5-1 & -5
For E-stop button / safety stop button
EN ISO 13850:2008
For E-stop button / safety stop button
Certification
cULus
