7 Technical data
Manufacturer
Address:
ABB JOKAB SAFETY
Varlabergsvägen 11
434 39 Kungsbacka
Sweden
AS-i data
AS-i profile
For safe node: S-7.B.0
For non-safe node XXXXA: S-7.A.0
For non-safe node XXXXN: S-7.0
Addressing
M12-connector
Node address at delivery
Non-safe node: 0
Safe node 1: 31
Safe node 2: 30
Response time over AS-i bus
5 ms (+ response time of safety monitor)
Power supply
Operating voltage
30 VDC, AS-i bus. Tolerance 26.5 – 31.6 VDC.
Total current consumption
Safe node 1: 80 mA
Safe node 2: 80 mA
Non-safe node: 150 mA
General
Degree of protection
IP65
Ambient temperature
-25…+50°C
Size (HxLxW)
70,5 x 40 x 260 mm
(+13,5 mm M12 connector)
Weight
0.19 kg
Color
Box: Yellow
Emergency stop: Red
Illuminated push-button (without color filter): White
Key selector: Grey
Emergency stop:
Illuminated push-button:
Key selector:
Actuating force
22 ± 4 N
7 ±3 N
1,3 Nm max
Actuator travel
Approx. 4 mm to latch
Approx. 4 mm
± 45°
Mechanical life
> 50 000 operations
1000000
30000
B10d
65 000 operations
1300000
