14
Data to be
transferred over
the serial bus
(Modified 99-12)
In addition to the event code data transfer, the
input data (I data), output data (O data), set-
ting values (S), memorized data (V data) and
some other data can be read from the relay
module over the serial communication bus.
Further, part of the data can be changed over
the SPA bus by separate commands. All data
information is available in channel 0.
Data Code Data Values
direct.
Measured voltage U
12
I1 R 0...9.99 x U
n
Measured voltage U
23
I2 R 0...9.99 x U
n
Measured voltage U
31
I3 R 0...9.99 x U
n
Blocking of tripping of under- I4 R 0 = no blocking
voltage stage 1 = tripping of stage U<
blocked
Starting of overvoltage stage U> O1 R 0 = U> stage not started
1 = U> stage started
Tripping of overvoltage stage U> O2 R 0 = U> stage not tripped
1 = U> stage tripped
Starting of undervoltage stage U< O3 R 0 = U< stage not started
1 = U< stage started
Tripping of undervoltage stage U< O4 R 0 = U< stage not tripped
1 = U< stage tripped
Activated start value for stage U> S1 R 0.8...1.6 x U
n
Activated operate time t> or time S2 R 0.05...100 s or
multiplier k for stage U> 0.05...1.00
Activated start value for stage U< S3 R 0.4...1.2 x U
n
Activated operate time for stage U< S4 R 1...120 s
Activated checksum of switch- S5 R 0...255
group SG1
Start value for stage U>, S11 R 0.8...1.6 x U
n
set with the setting knob
Operate time or time multiplier for S12 R 0.05...100 s or
stage U>, set with the setting knob 0.05...1.00
Start value for stage U<, S13 R 0.4...1.2 x U
n
set with the setting knob
Operate time for stage U<, S14 R 1...120 s
set with the setting knob
Checksum of switchgroup SG1 S15 R 0...255
(set with the switches)
Remote setting percentage of the S21 R, W 0...999%
start value for stage U>
Remote setting percentage of S22 R, W 0...999%
operate time or time multiplier
for stage U>
Remote setting percentage of S23 R, W 0...999%
start value for stage U<
Remote setting percentage of S24 R, W 0...999%
operate time for stage U<
Remotely set checksum of S25 R, W 0...255
switchgroup SG1
