STEP 7 Continued
—
Figure 7a. Installation of breaker
—
Figure 7b. Installation of breaker
Remove knock out features before
assembly to breaker
Remove knock out features before
assembly to breaker
!
!
3
STEP 7
Install the pre-assembled breaker. Attach the breaker assembly to
-
ing stud [6] to 18 lb-in. Refer figure 7a. Attach to link assembly with
STEP 9
Note: Use M3 x 8 if the required screw is not available.
STEP 8
Remove the plastic wall (knock out) in terminal cover and install the
terminal cover on load side (slide down in as shown in figure 8).
—
—
Figure 8. Installation of terminal cover
STEP 11
Attach the blankout out plate [17] to the filler plate with thread
—
—
Figure 10. Tighten the bolted strap connection
STEP 10
Tighten all the three bolted strap connections (carriage bolt as-
sembly) at the vertical bus to 65 lb-in. It may be necessary to re-
move adjacent circuit breaker modules to allow access to the
bolted connections at the vertical bus.
Item 5 - screw to be assembled with screw
thread end projecting outside as shown
To Next Page
