Operation Manual / TPL76-C
8 Disassembly and assembly / 8.2 Module weights
© Copyright 2020 . All rights reserved. HZTL2485_EN Rev.G March 2020
Complete compressor casing internal part
Weight [kg]
TPL76-C
490
The total weight of the complete compressor casing internal part con-
sists of the following parts: the compressor casing internal part, the dif-
fuser and the wall insert.
Page 83 / 133
