TPU2000/2000R Modbus/Modbus Plus Automation Guide
109
Bit 4 = Reserved
Bit 3 = Reserved
Bit 2 = Reserved
Bit 1 = Reserved
Bit 0 = Reserved
Reserved
Reserved
Reserved
Reserved
Reserved (lsb rightmost)
41164 Logical Input
Reserved
Unsigned Integer 16 Bits
Reserved
41165 Logical Input
Bit 15 = 51P-3 (Note 3)
Bit 14 = 51N-3 (Note 3)
Bit 13 = 50P-3 (Note 3)
Bit 12 = 50N-3 (Note 3)
Bit 11 = 150P-3 (Note 3)
Bit 10 = 150N-3 (Note3)
Bit 9 = 46-3 (Note 3)
Bit 8 = 51G
Bit 7 = 50G
Bit 6 = 150G (Note 3)
Bit 5 = ECI3 (Note 3)
Bit 4 = Reserved
Bit 3 = Reserved
Bit 2 = Reserved
Bit 1 = Reserved
Bit 0 = Reserved
Unsigned Integer 16 Bits
Winding 3 Phase Instantaneous Overcurrent Control Enabled
(msb leftmost)
Winding 3 Neutral Instantaneous Overcurrent Control Enabled
1
st
Winding 3 Phase Time Overcurrent Control Enabled
1
st
Winding 2 Neutral Time Overcurrent Control Enabled
2
nd
Winding 3 Phase Time Overcurrent Control Enabled
2
nd
Winding 2 Neutral Time Overcurrent Control Enabled
Winding 3 Negative Sequence Control Enabled
Ground Time Overcurrent Function Enabled
1
st
Ground Instantaneous Overcurrent Function Enabled
2
nd
Ground Instantaneous Overcurrent Function Enabled
Storage of Data Fault Summary Capture Initiated
Reserved
Reserved
Reserved
Reserved
Reserved (lsb rightmost)
41166 Logical Input
Reserved
Unsigned Integer 16 Bits
Reserved
41167 Logical Input
Reserved
Unsigned Integer 16 Bits
Reserved
41168 Logical Input
Reserved
Unsigned Integer 16 Bits
Reserved
NOTE 1: Drop Out Time is 3 cycles for Alarm Signals. The alarms activate with each operation or power-up
until the counters are reset. The counter alarms are reset when the targets are reset.
NOTE 2: Two Winding Relay Only
NOTE 3: Three Winding Relay Only
(L): This signal is latched and is only reset upon a protocol control command (Section 3), WinECP, ECP, or
Front Panel Interface reset sequence.
Table 5-28. Physical Output Table (1 Register Defined)
Register Item Description
41169 Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = Reserved
Bit 7 = OUT 7
Bit 6 = OUT 6
Bit 5 = OUT 5
Bit 4 = OUT 4
Bit 3 = OUT 3
Bit 2 = OUT 2
Bit 1 = OUT 1
Bit 0 = TRIP
16 Bit Unsigned Integer
(msb leftmost bit)
(lsb rightmost bit)
