TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
128
Register
Address
Item Description (Multiplier if any)
41976 I Restraint Phase A-Winding 2 Unsigned 16 Bit (X 800)
41977 I Restraint Phase B-Winding 2 Unsigned 16 Bit (X 800)
41978 I Restraint Phase C-Winding 2 Unsigned 16 Bit (X 800)
41979 2nd Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41980 5th Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41981 All Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41982 2nd Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41983 5th Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41984 All Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41985 2nd Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41986 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41987 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41988 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41989 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41990 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41991 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41992 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41993 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41994 All Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41995 2nd Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41996 5th Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41997 All Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41998 2nd Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
41999 5th Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
42000 All Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
42001 2nd Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
42002 5th Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
42003 All Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
42004 I restraint Phase A-Winding 1 (Ang) Unsigned 16 Bit
42005 I restraint Phase B-Winding 1 (Ang) Unsigned 16 Bit
42006 I restraint Phase C-Winding 1 (Ang) Unsigned 16 Bit
42007 I restraint Phase A-Winding 2 (Ang) Unsigned 16 Bit
42008 I restraint Phase B-Winding 2 (Ang) Unsigned 16 Bit
42009 I restraint Phase C-Winding 2 (Ang) Unsigned 16 Bit
The 3 Winding Harmonic Fault Register Definition Table follows.
Table 5-38. 3 Winding Harmonic Fault Register Definitions
Register
Address
Item Description (Multiplier if any)
42561 Harmonic 3 Winding Fault Control
Register
1 = First Record
2 = Next Record
3 = Oldest Unreported Record
Fault Record Control Register
Unsigned 16 Bit
1 = Fill 42562 through 42604 with First Record in Data
Buffer.
2 = Fill 42562 through 42604 with next Record Data
pointed to in buffer.
3 = Fill 42562 through 42604 with the last (oldest
unreported) record of data.
42562 Parameter Flag Unsigned Integer 16 Bit
42563 Fault Type Element Unsigned 16 Bit
00 = 87T – % Differential Alarm
01 = 87H – High Set Inst. Differential Alarm
02 = 51P-1 – Winding 1 Phase Time Overcurrent
