TPU2000/2000R Modbus/Modbus Plus Automation Guide
129
Register
Address
Item Description (Multiplier if any)
03= 51P-2 – Winding 2 Phase Time Overcurrent
04 = 50P-1 – 1
st
Winding 1 Phase Inst. Overcurrent
05 = 50N-1 – 1
st
Winding 1 Neutral Inst. Overcurrent
06 = 150P-1 – 2
nd
Winding 1 Phase Inst. Overcurrent
07 =150N-1– 2
nd
Winding 1 Neutral Inst. Overcurrent
08 = 46-1 – Neg. Sequence 1 Inst. Time Overcurrent
09 = 51P-2 – Winding 2 Phase Time Overcurrent
10 = 51G-2 – Winding 2 Ground Time Overcurrent
11 = 50P-2– 1
st
Winding 2 Phase Inst. Overcurrent
12 =50G-2 – 1
st
Winding 2 Ground Inst. Overcurrent
13 = 150P-2 – 2
nd
Winding 2 Phase Inst. Overcurrent
14 = 150G-2 – 2
nd
Winding 2 Ground Inst. Overcurrent
15 = 46-2 – Neg. Sequence 2 Inst. Time Overcurrent
16 = ECI-1 – Event Capture Initiate 1
17 = ECI-2 – Event Capture Initiate 2
18 = Through Fault
19 = Harmonic Restraint
42564 Setting At Fault Event Unsigned 16 Bit
01 = Primary Settings
02 = Alternate 1 Settings
03 = Alternate 2 Settings
42565 Fault Record Number
Unsigned 16 Bit
(1 – 999, only last 32 kept)
42566 Year 2 digit 00 -99 Unsigned 16 Bit Year of Fault
42567 Month 1 - 12 Unsigned 16 Bit Month of Fault
42568 Day 1 - 31 Unsigned 16 Bit Day of Fault
42569 Hour 00 - 23 Unsigned 16 Bit Hour of Fault
42570 Minute 00 - 59 Unsigned 16 Bit Minute of Fault
42571 Second 00 - 59 Unsigned 16 Bit Second of Fault
42572 Hundredths of Seconds 0 - 99 Unsigned 16 Bit Hundredth Second of Fault Time
42573 Winding3 Tap Unsigned 16 Bit (X 10)
42574 I restraint Phase A-Winding 3 Unsigned 16 Bit (X 800)
42575 I restraint Phase B-Winding 3 Unsigned 16 Bit (X 800)
42576 I restraint Phase C-Winding 3 Unsigned 16 Bit (X 800)
42577 2nd Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42578 5th Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42579 All Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42580 2nd Harmonic Phase B-Winding 3 Unsigned 16 Bit (X 2)
42581 5th Harmonic Phase B-Winding 3 Unsigned 16 Bit (X 2)
42582 All Harmonic Phase B-Winding 3 Unsigned 16 Bit (X 2)
42583 2nd Harmonic Phase C-Winding 3 Unsigned 16 Bit (X 2)
42584 5th Harmonic Phase C-Winding 3 Unsigned 16 Bit (X 2)
42585 All Harmonic Phase C-Winding 3 Unsigned 16 Bit (X 2)
42586 I restraint Phase A-Winding 3 (Ang) Unsigned 16 Bit
42587 I restraint Phase B-Winding 3 (Ang) Unsigned 16 Bit
42588 I restraint Phase C-Winding 3 (Ang) Unsigned 16 Bit
42589 Winding 3 Tap Unsigned 16 Bit (X 10)
42590 I restraint Phase A-Winding 3 (Ang) Unsigned 16 Bit
42591 I restraint Phase B-Winding 3 (Ang) Unsigned 16 Bit
42592 I restraint Phase C-Winding 3 (Ang) Unsigned 16 Bit
42593 2nd Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42594 5th Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42595 All Harmonic Phase A-Winding 3 Unsigned 16 Bit (X 2)
42596 2nd Harmonic Phase B-Winding 3 Unsigned 16 Bit (X 2)
42597 5th Harmonic Phase B-Winding 3 Unsigned 16 Bit (X 2)
