ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
125
Register
Address
Item Description (Multiplier if any)
42441 Hour 00 - 23 Unsigned 16 Bit Hour of Fault
42442 Minute 00 - 59 Unsigned 16 Bit Minute of Fault
42443 Second 00 - 59 Unsigned 16 Bit Second of Fault
42444 Hundredths of Seconds 0 - 99 Unsigned 16 Bit Hundredth Second of Fault Time
42445 Clear Time Unsigned 16 Bit (X 1000) seconds
42446 Relay Time (MSW) Most Significant Word Unsigned16 Bit (X 1000)
42447 Relay Time (LSW) Least Significant Word Unsigned 16 Bit (X 1000)
42448 I Phase A-Winding 3 Unsigned 16 Bit (X 800)
42449 I PhaseB-Winding 3 Unsigned 16 Bit (X 800)
42450 I Phase C-Winding 3 Unsigned 16 Bit (X 800)
42451 I Neutral-Winding 3 Unsigned 16 Bit (X 800)
42452 I Ground Unsigned 16 Bit ( X 800)
42453 I Phase A-Winding 3 (Angle) Unsigned 16 Bit
42454 I Phase B-Winding 3 (Angle) Unsigned 16 Bit
42455 I Phase C-Winding 3 (Angle) Unsigned 16 Bit
42456 I Neutral-Winding 3(Angle) Unsigned 16 Bit
42457 I Ground (Angle) Unsigned 16 Bit
42458 I 0-2 – Zero Sequence Current
Winding 3
Unsigned 16 Bit
42459 I 1-2 – Positive Sequence
Current Winding 3
Unsigned 16 Bit
42460 I 2-2 – Negative Sequence
Current Winding 3
Unsigned 16 Bit
42461 I 0-3 (Ang) – Zero Sequence
Angle Winding 3
Unsigned 16 Bit
42462 I 1-3 (Ang) – Positive
Sequence Angle Winding 3
Unsigned 16 Bit
42463 I 2-3 (Ang) – Negative
Sequence Angle Winding 3
Unsigned 16 Bit
42464 Scale - Phase Wdg 3 Unsigned 16 Bit
42465 Scale – Neutral Wdg 3 Unsigned 16 Bit
42466 Scale – Ground Wdg 3 Unsigned 16 Bit
Harmonic Restraint Fault Record
The Harmonic Restraint Record Fault Buffer contains the last 32 Harmonic Restraint Faults. Each record displays
one harmonic restraint operation at a time and includes the information defined in Tables 5-37 and 5-38. As with
the previous fault buffers, one buffer is available detailing the data for a Two Winding TPU2000/TPU2000R. If
one has a Three Winding TPU2000R, then the Three Winding Harmonic Restraint Buffer is updated as per the
definitions shown in Table 5-37. Figure 5-42 illustrates the register mapping and control access for the Harmonic
Restraint Fault Record Buffer.
