TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
154
R
Bit 10: 150N-3 - 2
nd
Winding 3 Neutral
Time Overcurrent Alarm
1 = Select bit 0 = Normal
R
Bit 9: 46-3 - Winding 3 Negative
Sequence Time Overcurrent Alarm
1 = Select bit 0 = Normal
R
Bit 8: 51G - Ground Instantaneous
Overcurrent Alarm
1 = Select bit 0 = Normal
R
Bit 7: 50G - 1
st
Ground Time Overcurrent
Alarm
1 = Select bit 0 = Normal
R
Bit 6: 150G - 2
nd
Ground Time
Overcurrent Alarm
1 = Select bit 0 = Normal
Bit 5: Reserved
Bit 4: Reserved
Bit 3: Reserved
Bit 2: Reserved
Bit 1: Reserved
Bit 0: Reserved (lsb)
41447 Change Mask Word 4
Bit 15: Reserved (msb)
Bit 14: Reserved
Bit 13: Reserved
Bit 12: Reserved
Bit 11: Reserved
Bit 10: Reserved
Bit 9: Reserved
Bit 8: Reserved
Bit 7: Reserved
Bit 6: Reserved
Bit 5: Reserved
Bit 4: Reserved
Bit 3: Reserved
Bit 2: Reserved
Bit 1: Reserved
Bit 0: Reserved (lsb)
41448 Set/Reset Mask Register 1
R
Bit 15: 87T - 3 % Phase Differential
Current Alarm
0 = Reset (msb)
R
Bit 14: 87H - 3 Instantaneous Phase
Differential Current Alarm
0 = Reset
R
Bit 13: 2HROA - Second Harmonic
Restraint Alarm
0 = Reset
R
Bit 12: 5HROA - 5
th
Harmonic Restraining
Alarm
0 = Reset
R
Bit 11: AHROA - All Harmonics Restraint
Alarm
0 = Reset
R
Bit 10: 51P-1 - Winding 1 Phase Time
Overcurrent Trip Alarm
0 = Reset
R
Bit 9: 51P-2 - Winding 2 Phase Time
Overcurrent Trip Alarm
0 = Reset
R
Bit 8: 50P-1 - 1
st
Winding 1 Phase
Instantaneous Overcurrent Trip Alarm
0 = Reset
R
Bit 7: 150P-1 - 2
nd
Winding 1 Phase
Instantaneous Overcurrent Trip Alarm
0 = Reset
R
Bit 6: 50P-2 - 1
st
Winding 2 Phase
Instantaneous Overcurrent Trip Alarm
0 = Reset
R
Bit 5: 150P-2 - 2
nd
Winding 1 Phase
Instantaneous Overcurrent Trip Alarm
0 = Reset
