ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
195
Register
Address
Item Description
1<=Range<=12 *10
0.2<=Range<=2.4 * 50
61062 51P-2 Time Dial /Delay Setting Unsigned 16 Bits
Dial : 1<=Range<=10 *20
Delay : 0<=Range<=10 * 20
61063 51P-2 Curve Select (TYPE I ) Unsigned 16 Bits
Range 0-12 (See Text Above)
61064 51P-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61065 51P-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61066 51P-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 ( See Text Above)
61067 51P-2 Pickup X Amps Unsigned 16 Bits
0.5<=Range<=20 Amp * 10 (See Note)
61068 51P-2 Time Dial/Time Delay Unsigned 16 Bits
Time Dial * 10
Time Delay * 20
61069 46-2 Curve Select (TYPE I) Unsigned Integer 16 bits
See Table Above
61070 46-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61071 46-2 Time Dial/ Time Delay Unsigned 16 Bits
1<=Range<=10 * 20
0<=Range<= 10 *20
61072 51G-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61073 51G-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61074 51G-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 * 20 : Time Dial
0<=Range<=10 * 20 : Time Delay
61075 50G-2 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61076 51G-2 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61077 51G-2 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
61078 150G-2 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
61079 150G-2 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61080 150G-2 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
61081 Disturb 2 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=5 *10
61082 Level Detector-1 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=20 *10 , 201 = Disable
61083 Level Detector-1 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=20 *10 , 201 = Disable
61084 Unit Configuration Byte Unsigned Integer 16 Bits (rightmost bit)
