TPU2000/2000R Modbus/Modbus Plus Automation Guide
239
63234 RESERVED
Authentication
ASCII – 2 Characters
63235 RESERVED
Authentication
ASCII – 2 Characters
63236 RESERVED
Authentication
ASCII – 2 Characters
63237 RESERVED
Authentication
ASCII – 2 Characters
63238 RESERVED
Authentication
ASCII – 2 Characters
63239 RESERVED
Authentication
ASCII – 2 Characters
63240 RESERVED
Authentication
ASCII – (Rightmost) 2 Characters
63241 RESERVED Local P
Selector
ASCII (Leftmost 2 Characters)
63242 RESERVED Local P
Selector
ASCII – 2 Characters
63243 RESERVED Local P
Selector
ASCII – 2 Characters
63244 RESERVED Local P
Selector
ASCII – 2 Characters
63245 RESERVED Local P
Selector
ASCII – 2 Characters
63246 RESERVED Local P
Selector
ASCII – 2 Characters
63247 RESERVED Local P
Selector
ASCII – 2 Characters
63248 RESERVED Local P
Selector
ASCII – 2 Characters
63249 RESERVED Local P
Selector
ASCII – 2 Characters
63250 RESERVED Local P
Selector
ASCII – 2 Characters
63251 RESERVED Local P
Selector
ASCII – 2 Characters
63252 RESERVED Local P
Selector
ASCII – (Rightmost) 2 Characters
63253 RESERVED Local S
Selector
ASCII (Leftmost 2 Characters)
63254 RESERVED Local S ASCII – 2 Characters
