TPU2000/2000R Modbus/Modbus Plus Automation Guide
263
Byte-Bit
Output Input Byte-Bit Output Input
3-7 51G-2 ALT1 4-7 87H-D ULI1
3-6 50N-1 ALT2 4-6 51P-1D ULI2
3-5 150N-1 ECI1 4-5 51P-2D ULI3
3-4 50G-2 ECI2 4-4 51N-1D ULI4
3-3 150G-2 WCI 4-3 51G-2D ULI5
3-2 46-1 TRIP 4-2 50P-1D ULI6
3-1 46-2 SPR 4-1 50P-2D ULI7
3-0 87T-D TCM 4-0 50N-1D ULI8
Byte-Bit
Output Input Byte-Bit Output Input
5-7 50G-2D ULI9 6-7 PBTA
5-6 150P-1D CRI 6-6 PCTA
5-5 150P-2D 6-5 PUA
5-4 150N-1D 6-4 63
5-3 150G-2D 6-3 THRUFA
5-2 46-1D 6-2 TFCA
5-1 46-2D 6-1 TFKA
5-0 PATA 6-0 TFSCA
Byte-Bit
Output Input Byte-Bit Output Input
7-7 DTC 8-7 87T*
7-6 OCTC 8-6 87H*
7-5 PDA 8-5 2HROA*
7-4 NDA 8-4 5HROA*
7-3 PRIM 8-3 AHROA*
7-2 ALT1 8-2 51P-1*
7-1 ALT2 8-1 51P-2*
7-0 STCA 8-0 50P-1*
Byte-Bit
Output Input Byte-Bit Output Input
9-7 150P-1* 10-7 150G-2*
9-6 50P-2* 10-6 46-1*
9-5 150P-2* 10-5 46-2*
9-4 51N-1* 10-4 63*
9-3 51G-2* 10-3 ULO1
9-2 50N-1* 10-2 ULO2
9-1 150N-1* 10-1 ULO3
9-0 50G-2* 10-0 ULO4
Byte-Bit
Output Input Byte-Bit Output Input
11-7 ULO5 12-7 HLDA-1
11-6 ULO6 12-6 LLDA-1
11-5 ULO7 12-5 HLDA-2
11-4 ULO8 12-4 LLDA-2
11-3 ULO9 12-3 HPFA
11-2 LOADA 12-2 LPFA
11-1 OCA-1 12-1 VarDA
11-0 OCA-2 12-0 PVArA
Byte-Bit
Output Input Byte-Bit Output Input
13-7 NVArA 14-7 Spare
13-6 PWatt1 14-6 Spare
13-5 PWatt2 14-5 Spare
13-4 Spare 14-4 Spare
13-3 Spare 14-3 Spare
13-2 Spare 14-2 Spare
