TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
284
92 HPFA High Power Factor Alarm
93 LPFA Low Power Factor Alarm
94 VarDA Three Phase kVar Demand Alarm
95 PVArA Positive 3 Phase kiloVAr Alarm
96 NVArA Negative 3 Phase kiloVAr Alarm
97 PWatt1 Positive Watt Alarm 1
98 PWatt2 Positive Watt Alarm 2
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x46
1/3 Total Number of Messages = 14
2/1 spare (bits 24-31)
2/2 spare (bits 16-23)
2/3 Programmable output AND/OR selection bits 8-15
3/1 Programmable output AND/OR selection bits 0-7
3/2 OUTPUT1 index byte
3/3 OUTPUT2 index byte
4/1 OUTPUT3 index byte
4/2 OUTPUT4 index byte
4/3 OUTPUT5 index byte
5/1 OUTPUT6 index byte
5/2 OUTPUT7 index byte
5/3 OUTPUT8 index byte
6/1 OUTPUT9 index byte
6/2 OUTPUT10 index byte
6/3 OUTPUT11 index byte
7/1 OUTPUT12 index byte
7/2 OUTPUT13 index byte
7/3 OUTPUT14 index byte
8/1 OUTPUT15 index byte
8/2 OUTPUT16 index byte
8/3 OUTPUT17 index byte
9/1 OUTPUT18 index byte
9/2 OUTPUT19 index byte
9/3 OUTPUT20 index byte
10/1 OUTPUT21 index byte
10/2 OUTPUT22 index byte
10/3 OUTPUT23 index byte
11/1 OUTPUT24 index byte
11/2 OUTPUT25 index byte
11/3 OUTPUT26 index byte
12/1 OUTPUT27 index byte
12/2 OUTPUT28 index byte
12/3 OUTPUT29 index byte
13/1 OUTPUT30 index byte
13/2 OUTPUT31 index byte
13/3 spare
14/1 spare
14/2 Checksum high byte
14/3 Checksum low byte
4.7 Transmit Programmable Output User Defined Strings ( 3 4 7 )
User definable 8 char output strings. Byte 9 is an implied NULL
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x47
