TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
286
5 = Percent 25 Tap
6 = Percent 40 Tap
7 = User Curve 1
8 = User Curve 2
9 = User Curve 3
Mode Selection Type 87T
0 = Disabled
1 = 2nd Harmonics
2 = 2nd & 5th Harmonics
3 = All Harmonics
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = (Prim=0x48, Alt1=0x49, Alt2=0x4a)
1/3 Total Number of Messages = 25
2/1 87T Curve byte (Type 87T)
2/2 87T Minimum I Operate (0.2-1.0 *10)
2/3 87T Percent Restraint (15-60)
3/1 87T Restraint Mode (Mode Selection Type 87T)
3/2 87T 2nd Harmonic Restraint high byte(7.5-25 *10)
3/3 87T 2nd Harmonic Restraint low byte
4/1 87T 5th Harmonic Restraint high byte (15-40 *10)
4/2 87T 5th Harmonic Restraint low byte
4/3 87T All Harmonics Restraint high byte (15-40 *10)
5/1 87T All Harmonics Restraint low byte
5/2 87H Tap X byte (6-20 *10)
5/3 87T-1 Tap Amp (2-9 Amp *10, 0.4-1.8 Amp *50)
6/1 51P-1 Curve Select byte (Type I)
6/2 51P-1 Pickup Amp/OA (1-12 Amp *10, 0.2-2.4Amp *50)
6/3 51P-1 Timedial/delay (dial 1-10 *20, delay 0-10 *20)
7/1 50P-1 Curve Select byte (Type II)
7/2 50P-1 Pickup X byte (0.5-20.0, *10)
7/3 50P-1 Timedial/delay high byte (dial *10,delay *100)
8/1 50P-1 Timedial/delay low (dial 1-10, delay 0-9.99)
8/2 150P-1 Curve Select byte (Type II)
8/3 150P-1 Pickup X (0.5-20, *10)
9/1 150P-1 Timedial high byte (0-9.99, *100)
9/2 150P-1 Timedial low byte
9/3 46-1 Curve Select byte (Type I)
10/1 46-1 Pickup Amp byte (1-12 Amp *10, 0.2-2.4Amp *50)
10/2 46-1 Timedial/delay (dial 1-10 *20, delay 0-10 *20)
10/3 51N-1 Curve Select byte (Type I)
11/1 51N-1 Pickup Amp byte (1-12 Amp *10, 0.2-2.4Amp *50)
11/2 51N-1 Timedial/delay (dial 1-10 *20, delay 0-10 *20)
11/3 50N-1 Curve Select byte (Type II)
12/1 50N-1 Pickup X byte (0.5-20, *10)
12/2 50N-1 Timedial/delay high byte (dial *10,delay *100)
12/3 50N-1 Timedial/delay low (dial 1-10, delay 0-9.99)
13/1 150N-1 Curve Select byte (Type II)
13/2 150N-1 Pickup X byte (0.5-20, *10)
13/3 150N-1 Time Delay high byte (0-9.99, *100)
14/1 150N-1 Time Delay low byte
14/2 87T-2 Tap Amp byte (2-9 Amp *10, 0.4-1.8 Amp *50)
14/3 51P-2 Curve Select byte (Type I)
15/1 51P-2 Pickup Amp/OA (1-12 Amp *10, 0.2-2.4Amp *50)
15/2 51P-2 Timedial/delay (dial 1-10 *20, delay 0-10 *20)
15/3 50P-2 Curve Select byte (Type II)
16/1 50P-2 Pickup X byte (0.5-20, *10)
