TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
288
2/2 Wdg1 P CT Ratio low byte
2/3 Wdg1 N CT Ratio high byte (1-4000)
3/1 Wdg1 N CT Ratio low byte
3/2 Wdg2 P CT Ratio high byte (1-4000)
3/3 Wdg2 P CT Ratio low byte
4/1 Wdg2 G CT Ratio high byte (1-4000)
4/2 Wdg2 G CT Ratio low byte
4/3 Winding Phase Comp high byte (0-330, /30)
5/1 Winding Phase Comp low byte
5/2 Wind 1 CT Config high byte (0=Wye; 1=Delta, IA-IC; 2=Delta, IA-IB)
5/3 Wind 1 CT Config low byte
6/1 Wind 2 CT Config high byte (0=Wye; 1=Delta, IA-IC; 2=Delta, IA-IB)
6/2 Wind 2 CT Config low byte
6/3 Phase Rotation high byte (0=ABC, 1=ACB)
7/1 Phase Rotation low byte
7/2 Alt 1 Settings high byte (0=Disable, 1=Enable)
7/3 Alt 1 Settings low byte
8/1 Alt 2 Settings high byte (0=Disable, 1=Enable)
8/2 Alt 2 Settings low byte
8/3 Trip Failure Mode high byte (Type Trip Failure)
9/1 Trip Failure Mode low byte
9/2 Trip Failure Time high byte (5-60)
9/3 Trip Failure Time low byte
10/1 Trip Fail Dropout % PU high byte (5-90)
10/2 Trip Fail Dropout % PU low byte
10/3 Configuration Flag high byte
bit 8 : Cross Block Mode (0=Disable, 1=Enable)
bit 9 : SPARE
bit 10 : SPARE
bit 11 : SPARE
bit 12 : SPARE
bit 13 : SPARE
bit 14 : SPARE
bit 15 : SPARE
11/1 Configuration Flag low byte
bit 0 : OC Protect Mode (0=Fund, 1=RMS)
bit 1 : Reset Mode (0=Instant 1=Delayed)
bit 2 : Spare
bit 3 : Target Display Mode (0=Last, 1=All)
bit 4 : Local Edit (0=Disable, 1=Enable)
bit 5 : Remote Edit (0=Disable, 1=Enable)
bit 6 : WHr/VARHr Meter Mode (0=KWHr, 1=MWHr)
bit 7 : LCD Light (0=Timer, 1=On)
11/2-16/1 Unit Name character 1-15
16/2 Transformer Configuration Byte (0=Wye1-Wye2, 1=Wye1-Delta2, 2=Delta1-Wye2, 3=Delta1-
Delta2)
16/3 Demand Time Const high byte (Type Demand Time)
17/1 Demand Time Const low byte
17/2 LCD Contrast Adj high byte (0-63)
17/3 LCD Contrast Adj low byte
18/1 Relay Password character 1
18/2 Relay Password character 2
18/3 Relay Password character 3
19/1 Relay Password character 4
19/2 Meter Winding Mode (0=Wdg1, 1=Wdg2, 2=Wdg3)
19/3 VT Configuration (0=69VWye, 1=120VWye, 2=120V Delta, 3=208V Delta)
20/1 VT Ratio high byte (1-4500)
20/2 VT Ratio low byte
20/3 Spare
