TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
290
8/1 Low PF Alarm high byte(0.5-1.0 *100, 101=Disables)
8/2 Low PF Alarm low byte
8/3 High PF Alarm high byte(0.5-1.0 *100, 101=Disables)
9/1 High Pf Alarm low byte
9/2 Positive kVAR Alarm high byte (10-99990 / 10,10000=Disable)
9/3 Positive kVAR Alarm low byte
10/1 Negative kVAR Alarm high byte (10-99990 /10,10000=Disable)
10/2 Negative kVAR Alarm high byte
10/3 Pos Watt Alarm 1 high byte (1-9999, 10000=Disable)
11/1 Pos Watt Alarm 1 low byte
11/2 Pos Watt Alarm 2 high byte (1-9999, 10000=Disable)
11/3 Pos Watt Alarm 2 low byte
12/1 Spare
12/2 Spare
12/3 Spare
13/1 Spare
13/2 Spare
13/3 Spare
14/1 Spare
14/2 Spare
14/3 Spare
15/1 Spare
15/2 Spare
15/3 Spare
16/1 Spare
16/2 Spare
16/3 Spare
17/1 Spare
17/2 Checksum high byte
17/3 Checksum low byte
4.14 Transmit Real Time Clock ( 3 4 14 )
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x4e
1/3 Total Number of Messages = 4
2/1 Hours byte (0-23)
2/2 Minutes byte (0-59)
2/3 Seconds byte (0-59)
3/1 Day byte (0-31), (0=Shutdown Clock)
3/2 Month byte (1-12)
3/3 Year byte (0-99)
4/1 Spare
4/2 Checksum high byte
4/3 Checksum low byte
4.15 Transmit Programmable Output Delays ( 3 4 15 )
Msg Byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x4f
1/3 Total Number of Messages = 8
2/1 OUT 5 delay high byte (0.00-60, *100)
2/2 OUT 5 delay low byte
2/3 OUT 7 delay high byte (0.00-60, *100)
3/1 OUT 7 delay low byte
3/2 OUT 4 delay high byte (0.00-60, *100)
3/3 OUT 4 delay low byte
