TPU2000/2000R Modbus/Modbus Plus Automation Guide
293
25/2 I2-2 Angle Lo byte
25/3 Spare
26/1-29/3 Reserved for Tap Changer Position
5.2 Show Demand Currents Data ( 3 5 2 )
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x52
1/3 Total Number of Messages = 6
2/1 Aux. Status byte (see command 3 5 1, msg 2/1)
2/2 Demand Ia Hi byte (Load Currents)
2/3 Demand Ia Mid byte
3/1 Demand Ia Lo byte
3/2 Demand Ib Hi byte
3/3 Demand Ib Mid byte
4/1 Demand Ib Lo byte
4/2 Demand Ic Hi byte
4/3 Demand Ic Mid byte
5/1 Demand Ic Lo byte
5/2 Demand In/Ig Hi byte
5/3 Demand In/Ig Mid byte
6/1 Demand In/Ig Lo byte
6/2 Spare
6/3 Spare
5.3 Show Maximum Demand Currents Data ( 3 5 3 )
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x53
1/3 Total Number of Messages = 12
2/1 Aux. Status byte (see command 3 5 1, msg 2/1)
2/2 Max Dem Ia Hi byte (Load Currents)
2/3 Max Dem Ia Mid byte
3/1 Max Dem Ia Lo byte
3/2 Max Dem Ia time yy
3/3 Max Dem Ia time mn
4/1 Max Dem Ia time dd
4/2 Max Dem Ia time hh
4/3 Max Dem Ia time mm
5/1 Max Dem Ib Hi byte
5/2 Max Dem Ib Mid byte
5/3 Max Dem Ib Lo byte
6/1 Max Dem Ib time yy
6/2 Max Dem Ib time mn
6/3 Max Dem Ib time dd
7/1 Max Dem Ib time hh
7/2 Max Dem Ib time mm
7/3 Max Dem Ic Hi byte
8/1 Max Dem Ic Mid byte
8/2 Max Dem Ic Lo byte
8/3 Max Dem Ic time yy
9/1 Max Dem Ic time mn
9/2 Max Dem Ic time dd
9/3 Max Dem Ic time hh
10/1 Max Dem Ic time mm
10/2 Max Dem In/Ig Hi byte
10/3 Max Dem In/Ig Mid byte
