TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
302
169 ULI4 Input Opened
170 ULI5 Input Closed
171 ULI5 Input Opened
172 ULI6 Input Closed
173 ULI6 Input Opened
174 ULI7 Input Closed
175 ULI7 Input Opened
176 ULI8 Input Closed
177 ULI8 Input Opened
178 ULI9 Input Closed
179 ULI9 Input Opened
180 CRI Input Closed
181 CRI Input Opened
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x5c
1/3 Total Number of Messages = 5
2/1 Year
2/2 Month
2/3 Day
3/1 Hour
3/2 Minute
3/3 Second
4/1 Hundredths of second
4/2 Message Number
4/3 Value (if any) Hi byte
5/1 Value (if any) Lo byte
5/2 Operation Number (high byte)
5/3 Operation Number (low byte)
If the operation entry doesn't exist then send 0's in all the bytes 2/1 through 5/3.
5.13 Send Next Operations Record ( 3 5 13 )
Same format as ( 3 5 12 ) except Msg 1/2 = 0x5d.
5.14 Breaker Status (Including I/O Status) ( 3 5 14 )
Input status bit 0=opened, 1=closed.
Output status bit 0=de-energized, 1=energized.
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x5e
1/3 Total Number of Messages = 3
2/1 Contact Input Status (high byte)
Bit 0 - Input 9
Bit 1 - Spare
Bit 2 - Spare
Bit 3 - Spare
Bit 4 - Spare
Bit 5 - Spare
Bit 6 - Spare
Bit 7 - Spare
2/2 Contact Input Status (low byte)
Bit 0 - Input 1
Bit 1 - Input 2
Bit 2 - Input 3
