TPU2000/2000R Modbus/Modbus Plus Automation Guide
309
28/3 I restraint C-1 Lo byte
29/1 I restraint A-2 Hi byte (*800)
29/2 I restraint A-2 Lo byte
29/3 I restraint B-2 Hi byte (*800)
30/1 I restraint B-2 Lo byte
30/2 I restraint C-2 Hi byte (*800)
30/3 I restraint C-2 Lo byte
31/1 2nd Harmonic A-1 byte (*2)
31/2 5th Harmonic A-1 byte (*2)
31/3 All Harmonics A-1 byte (*2)
32/1 2nd Harmonic B-1 byte (*2)
32/2 5th Harmonic B-1 byte (*2)
32/3 All Harmonics B-1 byte (*2)
33/1 2nd Harmonic C-1 byte (*2)
33/2 5th Harmonic C-1 byte (*2)
33/3 All Harmonics C-1 byte (*2)
34/1 2nd Harmonic A-2 byte (*2)
34/2 5th Harmonic A-2 byte (*2)
34/3 All Harmonics A-2 byte (*2)
35/1 2nd Harmonic B-2 byte (*2)
35/2 5th Harmonic B-2 byte (*2)
35/3 All Harmonics B-2 byte (*2)
36/1 2nd Harmonic C-2 byte (*2)
36/2 5th Harmonic C-2 byte (*2)
36/3 All Harmonics C-2 byte (*2)
37/1 I Restraint A-1 (ang) Hi byte
37/2 I Restraint A-1 (ang) Lo byte
37/3 I Restraint B-1 (ang) Hi byte
38/1 I Restraint B-1 (ang) Lo byte
38/2 I Restraint C-1 (ang) Hi byte
38/3 I Restraint C-1 (ang) Lo byte
39/1 I Restraint A-2 (ang) Hi byte
39/2 I Restraint A-2 (ang) Lo byte
39/3 I Restraint B-2 (ang) Hi Lo byte
40/1 I Restraint B-2 (ang) Lo Hi byte
40/2 I Restraint C-2 (ang) Hi byte
40/3 I Restraint C-2 (ang) Lo byte
41/1 Duration Most Significant Hi byte (*1000)
41/2 Duration Most Significant Lo byte
41/3 Duration Least Significant Hi byte
42/1 Duration Least Significant Lo byte
42/2 Spare
42/3 Spare
If no harmonic restraint data entry is present then send all 0s for 2/1 through 27/3.
6.11 Send Next Harmonic Restraint Record (3 6 11)
Same format as ( 3 6 10 ) except Msg 1/2 = 0x6b.
6.12 Oldest Unreported Differential Fault Record (3 6 12)
This command will report the oldest unreported differential fault record. The 3 0 4 command can be issued to determine the
number of unreported records that exist in the unit's queue. The issuance of the 3 6 12 command will decrement the unit's
counter by one record.
Unreported Command Byte
0 = Get Oldest Unreported, 1 = Repeat last command
