TPU2000/2000R Modbus/Modbus Plus Automation Guide
323
0 not used reserved for fixed DIFF TRIP
1 Contact OUT5
2 Contact OUT7
3 Contact OUT4
4 Contact OUT6
5 Contact OUT3
6 Contact OUT2
7 Contact OUT1
8 spare
9 spare
10 spare
11 spare
12 spare
13 spare
14 spare
15 spare
11.7 Receive Programmable Output User Defined Names (3 11 7)
User definable 8 char output strings. Byte 9 is an implied NULL.
Msg byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 spare
2/3 Command + Subcommand = 0xb7
3/1-5/2 OUT1 Character String 8 bytes
5/3-8/1 OUT2 Character String 8 bytes
8/2-10/3 OUT3 Character String 8 bytes
11/1-13/2 OUT4 Character String 8 bytes
13/3-16/1 OUT5 Character String 8 bytes
16/2-18/3 OUT6 Character String 8 bytes
19/1-21/2 OUT7 Character String 8 bytes
21/3-24/1 spare Character String 8 bytes
24/2-26/3 spare Character String 8 bytes
27/1-29/2 spare Character String 8 bytes
29/3-32/1 spare Character String 8 bytes
32/2-34/3 spare Character String 8 bytes
35/1-37/2 spare Character String 8 bytes
37/3-40/1 spare Character String 8 bytes
40/2 Checksum high byte
40/3 Checksum low byte
11.8,9,10 Receive Relay Settings ( 3 11 X )
( 3 11 8 ) = Primary Settings
( 3 11 9 ) = Alternate 1 Settings
( 3 11 10 ) = Alternate 2 Settings
Low byte consists of bits 0 through 7.
High byte consists of bits 8 through 15.
Curve Selection Type I
0 = Extremely Inverse
1 = Very Inverse
2 = Inverse
3 = Short Time Inverse
4 = Definite Time
